Model 5i Digital Force / Torque Indicator User’s Guide

13.2 Factory Settings

Parameter Setting

Set points

Upper Disabled (defaults to 80% of full scale, compression, when enabled)

Lower Disabled (defaults to 40% of full scale, compression, when enabled)

Filters

Current 8

Displayed 1024

Average mode Disabled

Initial Delay 0

Trigger Force / Torque 10% of full scale

Averaging Time (sec.) 5.0

External Trigger Disabled

DATA Key Functions

RS-232/USB Output Enabled

Mitutoyo Output Disabled

Memory Storage Enabled

Backlight Auto

Minutes 1

Serial/USB

RS-232 Output Selected Enabled

USB Output Selected Disabled

Baud Rate 9,600

Data Format Numeric + units

Auto Output Disabled

Outputs per Sec. 125

Mitutoyo BCD Output Disabled

Automatic Shutoff Enabled

Minutes 5

Beeps

Keys Enabled

Alerts Enabled

Set Points Momentary

LCD Contrast 10

Initial Settings

Units Depends on sensor

Mode Real Time

Passwords All passwords disabled
