Model 5i Digital Force / Torque Indicator User’s Guide
20
Units (available units depend on the sensor used)
LB Switch unit to pound-force
OZ Switch unit to ounce-force
KG Switch unit to kilogram-force
G Switch unit to gram-force
N Switch unit to Newton
MN Switch unit to milli-Newton
KN Switch unit to kilo-Newton
LBFT Switch unit to pound-foot
LBIN Switch unit to pound-inch
OZIN Switch unit to ounce-inch
KGM Switch unit to kilogram-meter
KGMM Switch unit to kilogram-millimeter
GCM Switch unit to gram-centimeter
NM Switch unit to Newton-meter
NCM Switch unit to Newton-centimeter
NMM Switch unit to Newton-millimeter
Basic Functions (available measurement directions depend on the sensor used)
CUR Current mode (real time mode) for primary reading
PT Peak Tension mode for primary reading
PC Peak Compression mode for primary reading
PCW Peak Clockwise mode for primary reading
PCCW Peak Counter-clockwise mode for primary reading
CLR Clear peaks
Z Zero display and perform the CLR function
Filters
FLTCn Digital filter for displayed readings
FLTPn Digital filter for current readings
n= 0-10, filter = 2
n
, ex: n=0= no filter, n=10=1024 samples averaged
Memory & Statistics
MEM Transmit all stored readings
STA Transmit statistics
Set Points
SPHD Disable high set point
SPLD Disable low set point
SPHn High set point. n=value (+ for compression, - for tension)
SPLn Low set point. n=value (+ for compression, - for tension)
Note: High set point value must be greater than low set point value if both values
are set to the same polarity.
USB/RS-232 Communication
FULL USB/RS-232 transmission with units
NUM USB/RS-232 transmission without units (only numeric values)
AOUTn Auto-transmit n times per second n=1,2,5,10,25,50,125,250. 0=disabled
Note: n = 1 = yields 50 times per second. This is provided for backward
compatibility with the legacy indicator model BGI.
Mitutoyo Communication
MIT Enable Mitutoyo output
MITD Disable Mitutoyo output
POL Mitutoyo output with polarity (+ for compression, - for tension)
