Datasheet

V1.0 – 10.06.2015
SG-Tronic GmbH [e-mail]
Trientlgasse 18c, 6020 Innsbruck, Austria www.sg-tronic.com
I/O:
Supply voltage
12V or 24V
USB (Power for programming only)
USB-B, 2.0
Inputs, no galvanic insulation
Common analog/digital
Fixed digital
Fixed analog
8
4
2
2
Digital Outputs, no galvanic insulation
Relay output parallel to digital
8
6
PIN Header, no Galvanic insulation
Logic level Input
Logic level Output
Communication
Internal Power
8 parallel to terminal Inputs
8 parallel to terminal Outputs
SPI (switchable), UART, Reset
+3,3V, +5V, GND
Terminal capacities:
Relay Output, Power Input
Strip length
Max. tightening torque
2,5mm² (24-12AWG)
6-7mm
0,5Nm
Digital, Analog Input Output
Strip length
Max. tightening torque
1,5mm² (30-16AWG)
5-6mm
0,2Nm
Pin header connector
26 Pin, Dual row, 2.54 pitch
Protection:
ESD HBM Class 0
Contact discharge: ±4kV
Air discharge: ±8kV
Supply input over current protection
Internal Fuse 8A
Relay Output
External Fuse required
Digital Output
Overload, short circuit, ESD
Signal Input
Overvoltage, ESD
Pin header connector
Current +5V, +3,3V
ESD
total 200mA, resettable fuse
