400 Operator And
455 D Control Panel Installation Manual
400 PARTS LIST
POS PART # DESCRIPTION QTY
1 2036 Galvanized Nut (8MM) 1
2 7220015 Rear Mounting Bracket 1
3 7284005 Rear Mounting Plate 1
4 7182075 Short Pin (Brass) 1
5 7228015 Rear Fork (Aluminum) 1
6 2037 Self Locking Nut (8MM) 1
8 70991015 Gasket (D80) 2
9 490325 Locking Cap Kit 1
10 N/A Self Tapping Screw (4MM) 1
11 7119475 Vibration Dampener 2
12 2365 Motor Bolt (4x50mm) 4
13 2366 Lock Washer (4mm) 4
14 N/A Nut (4mm) 4
15* 7700205 Motor 220VAC (8μF) 1
16 7119485 Vibration Dampener 2
17 7161825 Operator Body (06’) 1
18 N/A Vent Screw Label 1
19 7182175 Long Pin (Brass) 1
20 N/A T20 Torx (5x 20mm) 4
21 7110015 Oil Plug 1
22 2274 Vent Screw (4x6mm) 1
23 7094065 Washer (Copper) 1
POS PART # DESCRIPTION QTY
29 3204425 Pump 1.lt (Lobe Type) 1
30 N/A Pump Pin (4x28mm) 1
31 7090010015 O-Ring 3
32 3060 Washer 1
33 2069 Nut (Swivel Jam) 1
34 7073095 Swivel Joint (Square Type) 1
35 7220355 Front Mounting Bracket 1
36 N/A Star Washer 1
37 7119405 Plug (Protective Cover) 2
38 7019195 Tie Rods (Protective Cover) 2
39 4170015 End Cap (Protective Cover) 1
40 7272105 Protective Cover 1
41 3900985 Skin Pack 1
42 2167+ Seal kit 1
43 6115 Lubrication Engineer Oil 2
44** 2707 Capacitor 8μF 1
45 7228015+ Aluminum Fork Kit 1
• * 115VAC Motor Part Number Is 77000425
• ** 25µF Capacitor For Use With 115VAC Motor
Part Number Is 2705
EXPLODED VIEW, 400 CBAC
