2 Set Up the Audio Matrix
Switch
This device operates as part of the Control4 home
system, which requires physical and logical connections
to function as designed.
Essential setup tasks include:
1.Plan Your Physical Layout
2.Connect Input and Output Devices
3.Connect to the Network and Power
4.Set Up Logical Connections
5.Static IP Modifications
This chapter describes, in general terms, how to set up
physical connections required for the Audio Matrix Switch
and all associated devices. Refer to any device-specific
documentation for additional installation instructions.
To set up the logical connections required, refer to
Control4 Composer Pro User Guide software
documentation.
Plan Your Physical Layout
This section explains physical and logical connections
and can help you plan your physical connections.
Use a worksheet to plan your audio zones. Using the
worksheet provided in Table 1 on page 12, identify the
ports you will use for each planned devices and zones.
