SPEC NO: DSAA5610 REV NO: V.4 DATE: MAY/19/2005 PAGE: 2 OF 3

APPROVED: J. Lu CHECKED: Allen Liu DRAWN: B.H.LI

Selection Guide

Note:

θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.

Part No. Dice Lens Type

Iv (mcd)

@ 20mA

Viewing

Angle

Min. Typ.

2 θ

θ θ

θ 1/2

L-53MBC BLUE (GaN) WATER CLEAR 50 150

16°

Electrical / Optical Characteristics at TA=25°C

Absolute Maximum Ratings at TA=25°C

Notes:

1. 1/10 Duty Cycle, 0.1ms Pulse Width.

2. 2mm below package base.

3. 5mm below package base.

Symbol Parameter Device Typ. Max. Test ConditionsUnits

λpeak

Peak Wavelength Blue 430 nm IF=20mA

λD

Dominant Wavelength Blue 466 nm IF=20mA

∆λ1/2

Spectral Line Half-width Blue 60 nm IF=20mA

C Capacitance Blue 100 pF VF=0V;f=1MHz

VF Forward Voltage Blue 3.8 4.5 V IF=20mA

IR Reverse Current Blue 10 uA VR = 5V

Parameter Blue Units

Power dissipation 105 mW

DC Forward Current 30 mA

Peak Forward Current [1] 150 mA

Reverse Voltage 5 V

Operating / Storage Temperature -40°C To +85°C

Lead Solder Temperature [2] 260°C For 3 Seconds

Lead Solder Temperature [3] 260°C For 5 Seconds
