Data Sheet

Hole centre
to
component
centre
P2 6.35+1.3 6.35+1.3 6.35+1.3 12.7+1.3 12.7+1.3 19.05+1.3 19.05+1.3
Feed hole
centre to
bottom
edge of the
component
H**
16.5+0.3 16.5+0.3 16.5+0.3 16.5+0.3 16.5+0.3 16.5+0.3 16.5+0.3
18.5+0.5 18.5+0.5 18.5+0.5 18.5+0.5 18.5+0.5 18.5+0.5 18.5+0.5
Feed hole
centre to
top edge of
the
component
H1
H+Hcomponent
< H1 32.25
max.
H+Hcomponent
< H1 32.25
max.
H+Hcomponent
< H1 24.25 to
31.5
H+Hcomponent
< H1 25.0 to
31.5
.
H+Hcomponent
< H1 26.0 to
37.0
H+Hcomponent
< H1 30.0 to
43.0
H+Hcomponent
< H1 35.0 to
45.0
Lead
spacing
F
2.5+0.5 5+0.8/-0.2 7.5+0.8 10.0+0.8 15.0+0.8 22.5+0.8 27.5+0.8
Lead
diameter
d 0.4+0.05 0.5+0.05
*0.5+0.05 or
0.7+
0.07/-0.05
*0.5+0.05 or
0.7+
0.07/-0.05
0.8+0.08/-0.05 0.8+0.08/-0.05
*0.8+0.08/-0.05
or 1.0+0.1/-0.05
Component
alignment
delta h +2.0 max. +2.0 max. +3.0 max. +3.0 max. +3.0 max. +3.0 max. +3.0 max.
Total tape
thickness
t 0.7+0.2 0.7+0.2 0.7+0.2 0.7+0.2 0.7+0.2 0.7+0.2 0.7+0.2
Package
**
ROLL / AMMO / REEL AMMO / REEL
**Please give "H" dimension and desired packaging type when ordering.
* Diameter of leads see General Data.
** PCM 10 and PCM 15 can be crimped to PCM 7.5 mm. Position of components according to PCM 7.5 (sketch 1).
P0 = 12.7 or 15.0 is possible.
Dims. in mm.
Minimum packing units for capacitors with radial leads
Please clarify customer-specific deviations with the manufacturer.
Taping
