Data Sheet

Polcarbonate film and foil capacitors
for pulse applications in PCM 5 mm
Low induction and low damping with high resonant frequency. With almost linear capacitance
temperature coefficient.
High pulse duty. Reservoir and decoupling capacitors for high-speed
digital circuits.
Great variety of applications with severe temperature changes. Close tolerances
up to 2.5 %.
Available taped and reeled.
Technical Data
Dielectric: Polycarbonate film.
Capacitor electrodes: Metal foil.
Encapsulation: Flame retardent plastic case,
UL 94 V-0, with epoxy resin seal.
Colour: Yellow. Marking: Black.
Temperature range: -55° C to +100° C.
Test specifications: In accordance with
IEC 60384-12 and EN 131700.
Test category: 55/100/56 in accordance with IEC.
Insulation resistance at +20° C:
>= 5 x 10
5
megohms
(mean value: 1 x 10
6
megohms).
In accordance with IEC 60384-12 and EN 131700.
Measuring voltage: 100 V/1 min.
Dissipation factors at +20° C:
tan delta <= 2 x 10
-3
at 1 kHz
tan delta <= 4 x 10
-3
at 10 kHz
tan delta <= 8 x 10
-3
at 100 kHz
Capacitance tolerances: +/-20%, +/-10%,
+/-5%, +/-2.5%.
Maximum pulse rise time: 1000 V/microsecond for pulses equal to the
rated voltage.
Test voltage: 2 Ur, 2 sec.
Vibration: 6 hours at 10...2000 Hz and 0.75 mm displacement amplitude
or 10 g in accordance with IEC 60068-2-6.
Low air density: 1 kPa = 10 mbar in accordance with IEC 60068-2-13.
Bump test: 4000 bumps at 390 m/sec
2
in accordance with IEC
60068-2-29.
Voltage derating: A voltage derating factor of 1% per K must be applied
from +85° C for DC voltages and from +75° C for AC voltages.
Graphs:
Taping:
Impedance change with frequency (general guide)
General Data
Capaci-
tance
100VDC/63VAC* 250VDC/160VAC* 400VDC/220VAC*
*AC voltage: f <= 400 Hz;
1.4 x Urms + UDC <= Ur
**PCM = Printed circuit module
= lead spacing.
Dims. in mm
d = 0.5 Ø
Rights reserved to amend design data without prior notification.
W H L PCM** W H L PCM** W H L PCM**
100 pF
150 "
220 "
330 "
470 "
680 "
2.5
2.5
2.5
2.5
2.5
2.5
6.5
6.5
6.5
6.5
6.5
6.5
7.2
7.2
7.2
7.2
7.2
7.2
5
5
5
5
5
5
2.5
2.5
2.5
2.5
2.5
2.5
6.5
6.5
6.5
6.5
6.5
6.5
7.2
7.2
7.2
7.2
7.2
7.2
5
5
5
5
5
5
2.5
2.5
2.5
2.5
2.5
3.5
6.5
6.5
6.5
6.5
6.5
8.5
7.2
7.2
7.2
7.2
7.2
7.2
5
5
5
5
5
5
1000pF
1500 "
2200 "
3300 "
4700 "
6800 "
2.5
2.5
2.5
2.5
3.5
3.5
6.5
6.5
6.5
6.5
8.5
8.5
7.2
7.2
7.2
7.2
7.2
7.2
5
5
5
5
5
5
3.5
3.5
3.5
4.5
8.5
8.5
8.5
9.5
7.2
7.2
7.2
7.2
5
5
5
5
3.5
3.5
4.5
8.5
8.5
9.5
7.2
7.2
7.2
5
5
5
0.01 µF
0.015 "
4.5
4.5
9.5
9.5
7.2
7.2
5
5
WIMA
