In the example in Figure 2, port 1 (JA) is configured for RS-422/485 full duplex, port 2 (JB) is

configured for RS-232, port 3 (JC) is configured for TTL, and ports 4 to 8 (JD to JH) are

disabled.

When all jumpers are removed, the corresponding ports are completely disabled. The UART will

receive no data from these ports, even if an external source is driving the headers.

NOTE: There are eight solder jumpers on the back of the board that

correspond to the vertical (Px2) headers on the front of the board. (See

Figure 3 for location of Px2 headers). If necessary, you can ensure TxD

+/-

pins

on specified vertical headers remain active, even if the board is not in RS-

422/485 mode or is disabled, by shorting the appropriate jumper.

Software Installation

Xtreme/104-Plus and Xtreme/104-Plus Opto include support for Windows NT/CE/2000/Server

2003/XP/XPe/XPx64/Vista, Ardence RTX for Windows QNX 4/6, Linux and SCO

Unix/Openserver. Please refer to the

readme.txt

files found in the appropriate directories on the

Xtreme/104-Plus CD containing drivers and documentation. These files contain technical tips

or release notes concerning installation and configuration of the device driver. For further

information concerning software installation of Xtreme/104-Plus or Xtreme/104-Plus Opto

products please visit the Connect Tech website at

www.connecttech.com.

If you are interested in a device driver for an operating system not listed please contact the

Connect Tech Sales Department. Also, visit the Download Zone of the Support Center on the

Connect Tech website for the latest product manuals, installation guides, diagnostic utilities and

device driver software

Specifications

Operating Environment

 Storage temperature: -40° C to 125° C

 Operating temperature: -40° C to 85° C (standard version)

 Humidity: 95% non-condensing

Power Requirements

Xtreme/104-Plus RS-423 models

+5 V DC +/-5% @ 100 mA (max.) 2 port models

Xtreme/104-Plus RS-232/422/485 models

+5 V DC +/-5% @ 385 mA (max.) 4 port models

+5 V DC +/-5% @ 575 mA (max.) 8 port models

Xtreme/104-Plus RS-232/422/485/TTL models

+5 V DC +/-5% @ 575 mA (max.) 8 port models

Xtreme/104-Plus Opto RS-232/422/485 models

+5 V DC +/-5% @ 500 mA (max.) 2 and 4 port models
