Connect Tech BlueStorm/Express User Manual
Revision 0.02
14
Table 3: VHDCI-68 female pinouts (continued)
Pin
No.
Port
No.
RS-232
Signal
Signal
Direction
RS-422/485
Signal
Signal
Direction
30 4 DTR output RXD- input
31 4 RTS output RTS- output
32 4 DSR input CTS- input
33 4 RXD input TXD+ output
34 4 CTS input RTS+ output
35 5 TXD output TXD- output
36 5 RI input CTS+ input
37 5 DCD input RXD+ input
38 5 DTR output RXD- input
39 5 RTS output RTS- output
40 5 DSR input CTS- input
41 5 RXD input TXD+ output
42 5 CTS input RTS+ output
43 6 TXD output TXD- output
44 6 RI input CTS+ input
45 6 DCD input RXD+ input
46 6 DTR output RXD- input
47 6 RTS output RTS- output
48 6 DSR input CTS- input
49 6 RXD input TXD+ output
50 6 CTS input RTS+ output
51 5, 6 SG signal gnd. SR signal ref.
52 7, 8 SG signal gnd. SR signal ref.
53 7 TXD output TXD- output
54 7 RI input CTS+ input
55 7 DCD input RXD+ input
56 7 DTR output RXD- input
57 7 RTS output RTS- output
58 7 DSR input CTS- input
59 7 RXD input TXD+ output
60 7 CTS input RTS+ output
61 8 TXD output TXD- output
62 8 RI input CTS+ input
63 8 DCD input RXD+ input
64 8 DTR output RXD- input
65 8 RTS output RTS- output
66 8 DSR input CTS- input
67 8 RXD input TXD+ output
68 8 CTS input RTS+ output
Cable CBG009 will send the signals to eight DB-9 male connectors. See Table 2 for the DB-9
pinouts
