ContaminationSensor CS 1000 Communicating with the CS1000 via the RS-485 bus
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 94/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
Communicating with the CS1000 via the RS-485 bus
To communicate with the CS1000, start a terminal program (e,g, Hyperterminal) on
the PC.
Use the following settings to communicate via the COM interface:
Transfer rate (bps): 9600 Baud
Data bits: 8
Parity: None
Stop bits: 1
Log: None
The CS1000 can send and receive only HSI commands.
An overview of the HSI commands is provided in our "Getting started" guide for HSI
commands, p/no.: 3737763. This "Getting started" guide is available as a PDF on
request by e-mailing fltersystems@hydac.com.
Taking the CS1000 out of operation
To decommission, proceed as follows:
1. Disconnect and remove the electric connection to the CS.
2. Close any shut-off devices in the feed and return lines of the CS.
2. Depressurize the unit.
3. Remove the hydraulic connection lines to the CS.
4. Remove the CS.
Disposing of CS1000
Dispose of the packaging material in an environmentally-friendly manner.
After dismantling the unit and separating the various materials, dispose of the unit in
an environmentally friendly manner.
