Specifications

ContaminationSensor CS 1000 Reading the analog output
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 56/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
SAE classes acc. to AS 4059
The following SAE values can be read out via the analog output:
•
SAE A-D (SAEMAX)
Only one single value is output.
•
SAE A / B / C / D
All values are sequentially time-coded before output.
•
SAE A / SAE B / SAE C / SAE D
Only one value is output.
•
SAE+T
All values are sequentially time-coded before output.
•
HDA.SAE
All values are sequentially time-coded before output.
This signal is planned for the HDA 5500, but it can be used also in other
applications.
The current 4.8 … 19.2 mA or voltage 2.4 … 9.6 V of the output signal is dependent
on the ISO contamination class SAE = 0.0 … 14.0 (resolution 0.1 class) or an error
as shown in the table below:
Current I = SAE class / Error Voltage U =
I < 4,00 mA Cable break U < 2,00 V
4.0 mA < I < 4.1 mA Device error, device not ready 2,00 V < U < 2,05 V
4,1 mA < I < 4,3 mA Not defined 2,05 V < U < 2,15 V
4,3 mA < I < 4,5 mA Flow error
(The flow rate is too low.)
2,15 V < U < 2,25 V
4,5 mA < I < 4,8 mA Not defined 2,25 V < U < 2,40 V
I = 4,80 mA SAE 0 U = 2,4 V
I = 4,90 mA SAE 0,1 U = 2,45 V
I = 5,01 mA SAE 0,2 U = 2,51 V
… … …
I = 5,83 mA SAE 1 U = 2,92 V
I = 6,86 mA SAE 2 U = 3,43 V
I = 7,89 mA SAE 3 U = 3,95 V
I = 8,91 mA SAE 4 U = 4,46 V
I = 9,94 mA SAE 5 U = 4,97 V
I = 10,97 mA SAE 6 U = 5,49 V
I = 12,00 mA SAE 7 U = 6,00 V
I = 13,03 mA SAE 8 U = 6,52 V
I = 14,06 mA SAE 9 U = 7,03 V
I = 15,09 mA SAE 10 U = 7,55 V
I = 16,11 mA SAE 11 U = 8,06 V
I = 17,14 mA SAE 12 U = 8,57 V
I = 18,17 mA SAE 13 U = 9,09 V
