Specifications

ContaminationSensor CS 1000 Setting limit values
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 54/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
WITHIN
Within limit values
Lower limit ≤ all values ≤ upper
limit
After switch-on or start of a
measurement.
Becomes conductive again, when
a value < respective lower limit
or
a value > respective upper limit
OUTSDE
Outside limit
values
A value ≤ lower limit
or
A value ≥ upper limit
After switch-on or start of a
measurement.
Becomes conductive again when
the respective lower limit < all
values < respective upper limit
OFF
No switching
function
-
Conductive, except in the event of
an error
Mode 3 (M3) Switching output – OPEN Switching output –
CONDUCTIVE
5 consecutive measurements ≤
limit or measurement stopped
Measurement is currently in
progress and one or more of the
last 5 measured values > limit
Mode 4 (M4) Switching output – OPEN Switching output –
CONDUCTIVE
Start or result of
check
measurement after
test cycle time: a
value ≥ upper limit
For 5 consecutive measurements:
all values ≤ lower limit
or measurement stopped
Measurement is in progress and
during one or more of the last 5
measurements: a value > lower
limit
Upon the test cycle
time elapsing for
the duration of a
check
measurement
Is open again when all values <
upper limit Restart test cycle time
Test cycle time has elapsed
Single Mode
SINGLE
Switching output – OPEN
Switching output –
CONDUCTIVE
- Device ready function
Always CONDUCTIVE except in
the event of an error
