Setting limit values
The voltage supply to the CS1000 makes the switching output (SP1) conductive.
This condition is maintained for the initial measurement duration (WAIT period).
Depending on the measurement mode, the switching output can be used as a
Device ready function.
Mode 1 (M1) Switching output – OPEN
Switching output –
CONDUCTIVE
- Device ready function
Conductive, except in the event of
an error
Mode 2 (M2) Switching output – OPEN Switching output –
CONDUCTIVE
BEYOND
Above limit
≥ upper limit
After switch-on or start of a
measurement.
Becomes conductive again when
all values ≤ respective lower limit
BELOW
Below limit
≤ lower limit value
After switch-on or start of a
measurement.
Becomes conductive again when
a value ≥ respective upper limit
WITHIN
Within limit values
Lower limit ≤ measured value ≤
upper limit
After switch-on or start of a
measurement.
Becomes conductive again, when
a value < respective lower limit
or
a value > respective upper limit
OUTSDE
Outside limit
values
Measured value ≤ lower limit
or
measured value ≥ upper limit
After switch-on or start of a
measurement.
Becomes conductive again when
the respective lower limit < all
values < respective upper limit
OFF
OFF
-
Conductive, except in the event of
an error
Mode 2 (M2)
3-digit ISO code
Switching output – OPEN
Switching output –
CONDUCTIVE
BEYOND
Above limit
A value ≥ upper limit
After switch-on or start of a
measurement.
Becomes conductive again when
all values ≤ respective lower limit
BELOW
Below limit
All values ≤ lower limit
After switch-on or start of a
measurement.
Becomes conductive again when
a value ≥ respective upper limit
