ContaminationSensor CS 1000 Operating the CS1x2x using the keypad
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 47/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
ANA.OUT - Set output signal at the analog output
The set measured variable is output via the analog output (see page 55).
ANaOUT
Set analog output -
output signal
+
Description
NAsMAX
NAS Maximum
NAS
NAS class 2/5/15/25 (coded)
NAS+T
NAS class+temp. (coded)
TEMP
Fluid temperature
HDaISO
ISO for HDA 5500
HDaNAS
NAS or SAE for HDA 5500
ISO 2
ISO class 2
ISO 5
ISO class 5
ISO 15
ISO class 15
ISO
ISO 3-digit (coded)
ISO+T
ISO 3-digit + temp. (coded)
NAS 2
NAS class 2
NAS 5
NAS class 5
NAS 15
NAS class 15
NAS 25
NAS class 25
CANCEL
Discard changes and
exit
SAVE
Save changes and
exit
