ContaminationSensor CS 1000 Operating the CS1x2x using the keypad
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 43/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
ANaOUT
Set analog output -
output signal
+
Code
SAeMAX
SAE A-D
SAE
SAE class A/B/C/D (coded)
SAE+T
SAE class + temp. (Code)
TEMP
Fluid temperature
HDaISO
ISO for HDA 5500
HDaSAE
SAE for HDA 5500
ISO 4
ISO 4 code
ISO 6
ISO 6 code
ISO 14
ISO 14 code
ISO
ISO 3-digit (coded)
ISO+T
ISO 3-digit + temp. (coded)
SAE A
SAE class A
SAE B
SAE class B
SAE C
SAE class C
SAE D
SAE class D
CANCEL
Discard changes and
exit
SAVE
Save changes and
exit
