ContaminationSensor CS 1000 Operating the CS1x2x using the keypad
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 42/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
WITHIN
OUTSDE
LIMITS
LIMITS
LOWER
UPPER
M3
Filter to cleanliness
class and stop
o.k.
+
Description
MEAsCH
ISO
ISO Code
SAE
SAE class
TARGET
Target
cleanliness
M4
Filter to continuously
monitor cleanliness
class
+
Description
MEAsCH
ISO
ISO Code
SAE
SAE class
TARGET
Target
cleanliness
RSTART
Resume
filtration from
this class
CYCLE
60
Set test cycle
time
(1…1440
minutes)
SINGLE
Start single
measurement + stop
o.k.
NO SET
ANA.OUT - Set output signal at analog output
The measured variable set here is o
utput at the analog output (see page 55).
