SWT.OUT – Configure switching output
Here you can adjust the behavior of the switching output. The measurement mode
"M1 / M2 / M3 / M4 / SINGLE" is copied from the setting in the PowerUp menu and
can no longer be selected here.
SWtOUT
Configure switching
output
o.k.
Code
M1
Continuous measurement
M2
Continuous measurement and
switching
M3
Filter to cleanliness class and
stop
M4
Filter to continuously monitor
cleanliness class
SINGLE
Start single measurement +
stop
M1
Continuous
measurement
o.k.
NO SET
M2
Continuous
measurement and
switching
o.k.
+
SP1
MEAsCH
SAEMAX
SAE
ISO 4
ISO 6
ISO 14
ISO
TEMP
SAE A
SAE B
SAE C
SAE D
SwFNCT
Switching
function
OFF
BEYOND
BELOW
