ContaminationSensor CS 1000 Operating the CS1x2x using the keypad
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 34/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
Activate / deactivate keypad lock.
Activate or deactivate the keypad lock by pressing both keys simultaneously. When
the keypad lock is activated, the keypad is locked to prevent further input.
Keys The following appears in the
display (1 sec)
Description
+
LOCK
Activating key lock
+
UNLOCK
Deactivating key lock
The display switches to the preset display after 1 second.
When the supply voltage to the CS is disconnected, the activated keypad lock
"LOCK" is unlocked and reset to "UNLOCK".
Display FREEZE
This function makes it possible for you to call up the last 20 displayed values on the
display.
The active display is then frozen in the set MTIME cycle.
The display FREEZE function is based on a volatile memory and means that the
values can be called up only as long as the CS is supplied with power and the
sensor is in display FREEZE.
The measured values are automatically numbered, whereby the highest incremental
number represents the last measured value. That means that when the memory is
full (20 measured values), the value 20 is the most recent and the value 1 is the
oldest .
If the memory exceeds 20 display values, the oldest entry will be overwritten.
