ContaminationSensor CS 1000 Display rotatable/Adjustable As Needed
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 20/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
3.
Mounting to a mounting plate:
Mount to a mounting plate or control block
using 4 cylindrical screws having an M6
hexagonal socket according to ISO 4762.
Display rotatable/Adjustable As Needed
The display can be continuously rotated by a
total of 270°; 180° counterclockwise and 90°
clockwise.
Rotate the display by hand in the corresponding
direction.
No tools are required for rotating the display.
