ContaminationSensor CS 1000 CS1000 Features
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 16/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
CS1000 Features
The CS1000 Series Contamination Sensor is a stationary measurement unit for the
continuous monitoring of particulate contamination in hydraulic and lubrication
systems.
The CS is designed to be used in low- or high-pressure hydraulic and lubrication
circuits and test benches where a small amount of oil (between 30 ml/min and 500
ml/min) is diverted for measurement purposes.
The ContaminationSensor is approved for a maximum operating pressure (see
specification on type label) and viscosity of up to 1000 mm²/s.
Particulate contamination is detected with an optical measurement cell
The sensor is available with the following options:
with or without 6-digit display and keypad (can be rotated by 270°)
with a 4 … 20 mA or 2 … 10 V analog output
Results are output as a cleanliness code according to:
ISO 4406:1999 and SAE AS 4059(D) or
ISO 4406:1987 and NAS or ISO4406:1999 and SAE AS 4059(D)
pipe / hose installation or flange installation
All models feature an analog electric output and an RS485 interface for outputting
the measured cleanliness class. In addition, all CS1000's have a switching output.
CS1000 Restrictions on use
NOTICE
Impermissible operating media
The ContaminationSensor will be destroyed.
► Operate the CS1000 only with the permissible operating fluids:
- CS 1xx0 is suitable for operation with mineral oils or
mineral-oil-based raffinates.
- CS 1xx1 is suitable for phosphate esters.
► Note the maximum operating pressure of 350 bar / 5075 psi.
