ContaminationSensor CS 1000 Safety information
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 12/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
Improper use or use deviating from intended use
Improper use may result in hazard to life and limb.
Improper use is:
Improper connection of the CS voltage and sensor cables.
Operation with a non-approved fluid.
Operation with impermissibly high pressure
WARNING
Hydraulic systems are under pressure
Danger of bodily injury
► The hydraulic system must be depressurized
before performing any work on the hydraulic
system.
