ContaminationSensor CS 1000 Safety information
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 11/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
Explanation of Symbols and Warnings, etc.
The following designations and symbols are used in this manual to designate
hazards, etc.:
DANGER
DANGER denotes situations
which can lead to death if
safety precautions are not
observed.
WARNING
WARNING denotes situations
which can lead to death if
safety precautions are not
observed.
CAUTION
CAUTION denotes situations
which can lead to severe
injuries if safety precautions
are not observed.
NOTICE
NOTE denotes situations
which can lead to property
damage if safety precautions
are not observed.
Proper use
The ContaminationSensor module CS1000 was developed for the continuous
monitoring of particulate contamination in hydraulic and lubrication systems.
Analyzing the size and quantity of contamination enables quality standards to be
verified and documented, and the requisite optimization measures to be
implemented.
