ContaminationSensor CS 1000 Model Code
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 106/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
Model Code
CS 1 0 0 0-A-0-0 - 0 - 0 /- 000
Product
CS = ContamionationSensor
Series
1 = 1000 series
Contamination code
2 = ISO4406:1999; SAE AS4059 (D)
3 = ISO4406:1987; NAS 1638
ISO4406:1999; SAE AS4059 (D)
Options
1 = without display
2 = with display, continuously variable rotation by
270°
Fluids
0 = petroleum-based
1 = for phosphate esters
Analog interfaces
A = 4 … 20 mA
B = 2 … 10 V
Switching output
0 = Switch output threshold
Digital interface
0 = RS485
Electrical connection
0 = plug connection M12x1, 8-pin, pin, according to
VDE0627 or IEC61984
Hydraulic connection type
0 = Pipe or hose connection
1 = Flange connection
Modification Number
000 = Standard
