ContaminationSensor CS 1000 Checking/resetting default settings
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 101/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
Checking/resetting default settings
PowerUp menu
PowerUp menu Value
MODE M1
M.TIME 60
pPRTCT 0
ADRESS HECOM A
CALIB ISoNAS
(CS 13xx, only)
Mode Value
MODE M2 SP1 MEAS.CH
SAeMAX
MODE M2 SP1 SW.FNCT
BEYOND
MODE M2 SP1 LIMITS LOWER 17.15.12
MODE M2 SP1 LIMITS UPPER 21.19.16
MODE M3 MEAsCH ISO
MODE M3 TARGET 17.15.12
MODE M4 MEAsCH ISO
MODE M4 TARGET 17.15.12
MODE M4 RESTART
21.19.16
MODE M4 CYCLE 60
Measuring menu
Measuring Menu Value
DSPLY ISO
SWtOUT M1
ANaOUT HDaISO
