User's Manual

Connect One Introduction
1 Introduction
1.1 General
Description
Nano WiReach
™
SMT is a secure serial-to-
Wireless-LAN device server module that also
acts as a bridge to connect serial devices to
802.11b/g Wireless LANs. It includes the
iChip
™
CO2144 IP Communication
Controller
™
chip and Marvell 88W8686 WiFi
chipset. It is packaged in RoHS-compliant
ultra-slim form factor and uses an industry
standard pin-out. The Nano WiReach SMT
can also be interfaced to a 10/100BaseT
wired LAN and a USB cellular modem with
some external components and glue logic.
Nano WiReach SMT offers much more than
many other device servers on the market. It
acts as a security gap between the application
and the network; supports up to 10
simultaneous TCP/UDP sockets; two listening
sockets; a web server with two websites;
SMTP and POP3 clients; MIME attachments;
FTP and TELNET clients, and SerialNET
™
mode for serial-to-IP bridging.
Nano WiReach SMT supports the SSL3/TLS1
protocol for secure sockets, HTTPS and
FTPS, WEP, WPA and WPA2 WiFi
encryption.
Nano WiReach SMT minimizes the need to
redesign the host device hardware. It features
a standard economical SMT footprint
providing for low-cost placement on a host
PCB with provisions for an on-board or
external antenna. Minimal or no software
configuration is needed for Nano WiReach
SMT to access the Wireless LAN.
Connect One’s high-level AT+i
™
API
eliminates the need to add WiFi drivers,
security and networking protocols and tasks to
the host application. The AT+i SerialNET
operating mode offers a true plug-and-play
mode that eliminates any changes to the host
application.
Nano WiReach SMT firmware – the IP stack
and Internet configuration parameters – are
stored in an external flash memory. The
module is power-efficient: the core operates at
1.2V, while I/Os operate at 3.3V. Power Save
mode further reduces power consumption.
The II-EVB-365SMT evaluation board
provides an easy environment for testing the
Nano WiReach SMT prior to designing it into
your product.
1.2 Hardware
Description
Size: 37.0 x 20.0 x 2.5 mm
Core CPU: 32-bit RISC ARM7TDMI, low-
leakage, 0.13 micron, running at 48MHz
Operating Voltage: +3.3V+/-10%
Operating Humidity: 90% maximum (non-
condensing)
Operating Temperature Range:
-10° to 65°C (14° to 149°F)
Power Consumption:
Transmit – 250mA @16dbm
235mA @12dbm (typical)
Receive – 190mA (typical)
Power Save mode – 8mA
Optional : On-Board antenna
Optional: U.FL connector
Connection: 44 SMT pads
Host Interface: TTL Serial, SPI and USB 1.1
device.
A/D Input (see AT+I programmers manual)
Cellular Modem Interface: USB 1.1 Host
10/100BaseT LAN Interface: RMII (w/ext.
PHY)
RoHS-compliant; lead-free
1.3 Performance
Specifications
Host Data Rate: up to 3Mbps in serial mode
Serial Data Format (AT+i mode):
Asynchronous character; binary; 8 data bits;
no parity; 1 stop bit
SerialNET mode: Asynchronous character;
binary; 7 or 8 data bits; odd, even, or no
parity; 1 stop bit
Flow Control: Hardware (-RTS, -CTS) and
software flow control.
Nano WiReach SMTData Sheet 1-1
