10 Evaluation Board
The II-EVB-365smt evaluation board enables you to evaluate the Nano WiReach SMT without
hanging anything in your current development environment. Using a simple Windows-based
pplication on a PC, you can issue AT+i commands to the iChip CO2144 and get responses.
Note: The evaluation board supports serial host data rates of up to
c
a
1Mbps.
AT+i commands are used to configure parameter values into iChip’s flash memory and activate
ernet tasks such as email send, sockets, FTP sessions, configuration, and more.
l description of AT+i commands can be found in the AT+i Programmer’s Manual on Connect
ne’s website at: http://www.connectone.com/support.asp?did=35
Int
A ful
O
To help you evaluate the Nano WiReach SMT, Connect One supplies the iChip Config Utility. This
a Windows-based application that contains intuitive dialog boxes to fully configure iChip CO2144.
esn’t require any knowledge of AT+i commands. It also contains local firmware update
nctionality. The iChip Config Utility allows you to perform specific Internet communication tasks
uch as sending and receiving emails, activating iChip’s websites, entering SerialNET mode, and
ore. The latest iChip Config Utility version and user manual can be found on Connect One’s
ebsite under the Support section.
n board connectors allow a choice of Host interfaces:
• RS232 COM port
• SPI
• USB Device
is
It do
fu
s
m
w
O
