Open the housing
Warning! Hazard due to supply voltage and DC-voltage from the
solar modules. Only licenced electricity installers are authorized to
open the connection area. Only trained service staff are authorized
to open the separately insulation-enclosed power stage on condition
that it is not under voltage.
Opening connection area
Conergy WR
- insert screwdriver into the borehole (1) at the bottom of the Conergy WR
- unlock cover (2) of connection area by lifting the screwdriver carefully at
the end of its handle
- pull cover (2) of connection area downwards and away
Important! To close the connection area put on cover (2) and push it
forward until it reaches the locking position.
1.
2.
(1)
(2)
(2)
