User manual

ENGLISH
35
Led explanation
= Continous
= Flashing = Off
Status description LED 1 LED 2 LED 3
Connected to the computer
Formatting / Installation in progress
Unit is in standby or unit is starting up
Remote control activity
Recording in progress
The unit is turned on
Reset (held down)
Fast flashing
Disk error
(no disk, disk not detected, disk not formatted or disk damaged)
Slow flashing
Reset Mode
During the reinitialisation of the Media Titan, the blue indicator will be continuously lit whilst holding down
the “reset” button, then will remain continuous during starting up.
If the “reset” button is held down for at least 5 seconds, the 3 indicator lights will flash rapidly and
simultaneously.
Warning!
If you keep the “reset” button held down for 5 seconds more (being 10 seconds in total), the
product will be totally reformatted. All your data on the Harddisk will be erased!
• Blue light: lit when pressing RESET
• After 5 seconds of holding down RESET: the green, blue and red lights will flash.
• After 10 seconds. The green light will flash during the installation process.
