3. Product Overview
Front view
Back view
Nr Description Nr Description
1 USB-Host port 8 Composite video output
2 Infrared receiver 9 Stereo audio output
3 Status LED’s 10 Digital optical audio output
4 Reset button 11 HDMI output
5 Digital tuner – Antenna out 12 USB connector (to computer)
6 Digital tuner – Antenna in 13 2x USB-Host port
7 Network connection (RJ45) 14 DC Input (12V, 4A)
1
2 3 4
5 7 6
8 9 10 11 12 13 14
