Product guide

Fax: [phone] Email: [e-mail] Web: www.videcon.co.uk
50
Housings - Metro
Haydon
Metro
Cable Managed Housing
n Fully Cable Managed CCTV Camera Housing
n Side Opening For Ease Of Installation & Maintenance
n Weather Proof To IP67
n 3 Year Anti-Corrosion Warranty
n Manufactured From Die Cast Aluminium
n Quick Release Removable Top
Options
n METRO/230V 230V AC
n METRO/LV 12V DC / 24V AC
Haydon
METRO-EXT ARM
Extension Arm
Haydon
METRO-POLEMOUNT
Pole Mount Adapter
Haydon
METRO-CORNER
BRACKET
Corner Bracket
n 450mm Extension Arm
for the Metro CCTV
Camera Housing, C/W
Fittings
n Corner Wall Bracket for the
Metro CCTV Camera
Housing
n Ideal for fitting the Metro
CCTV Camera Housing to
corners of walls or
buildings
n Pole mount adapter for the
Metro CCTV Camera Housing
n Complete with two clamps
for pole sizes:
Clamp 1.67mm - 127mm
Clamp 2.83mm - 178mm
Haydon
HAY-LDVE
Small Lockable
Enclosure
Haydon
HAY-LDVR2
Large Lockable
Enclosur
e
n Small lockable enclosure
n Suitable to house the VXM4B-4 digital r
ecorder
n Capacity for 1 x standard VCR and 1 U Multiplexer
n Radial lock with interlocking cam
n 1.6mm mild steel case and 2mm fr
ont door
n Vented both sides and at back, BNC cable entry for
VCR and multiplexer, Two IEC plug slots
n External Dimensions: D 540 x W 510 x H 183 mm
n Internal Dimensions: D 510 x W 507 X H 155 mm
n Weight 10.9 Kg
n Lar
ge lockable enclosur
e
n Suitable to house the VXM4B-8 & VXM4-16 digital recorders
n Vented for good air flow reducing the risk of over heating
n Fr
ont venting to help air flow for fr
ont mounted hard drives
n Easy cable access for all cabling - power, BNCs etc
n External Dimensions: D 595 x W 510 x H 220mm
n Inter
nal Dimensions: D 560 X W 506 x H 185mm
n Weight 16.1Kg
HA
Y-LDVR2-F - as above plus
n 2 X 12V Fans expelling hot air from the cabinet @70 CFM
n 12V Power supply complete with mains cables
n W
eight 17Kg
