48
Mobile Solutions
Videcon
VM5BK-C
Colour Vehicle Reversing Kit
Colour TFT LCD
n 5 Inch Scr
een
n Speaker
200mW
n Contrast
150:1
n Brightness
300cd/m2
n W
eight 515g inc. Frame
n Dimensions
163 x 125 x 30.5mm
n Power
12V / 8W (Max)
n Remote Contr
ol
Camera
n IP66
n 1/3” CCD
n 12V / 1W / 350mA
n 380TVL
n 3.6mm lens
n AGC (Auto)
n 80 x 54 x 41mm
n 0.3kg with bracket
n -20
o
C to + 60
o
C
n Connection 4 pin miniatur
e DIN
R
Reverse Gear
As reverse gear is selected on
vehicle the camera picture
appears on screen
1 3 5
2 4
Cable Supplied
Camera
Additional Camera
VC5382
n 1/3" 420TVL 0 Lux (IR on) c/w 2.9mm fixed lens and IR's -
Additional camera for VM5BK-C
The VM5BK-C is a high resolution 5" colour monitor suitable for in-
vehicle use to provide clear images for reversing and / or turning
manoeuvres. This kit includes a weatherproof colour camera
designed to be mounted at the rear of a vehicle to provide
unobstructed viewing during reversing. For added ease of use, the
user can also choose whether to view a normal or more natural
'mirror-image' view.
Videcon
VLCD5PUP
LCD Screen
Videcon
VLCD7P
LCD Scr
een
n Resolution 960 (H) x 234 (V)
n Contrast
150:1, Brightness: 300cd/m2
n Colour System
PAL
n Video (AV) input Two way
n Pictur
e flip function
Manual flip pictur
e up/down, flip left/right
n Audio output
0.2W
n Power Supply DC 12V
n Dimensions
163(W) x 125(H) x 30.5(D)mm
n Net W
eight
430g
n Power Consumption 8W
n 7” Screen
n 250cd/m2
n Mini pin power input/output
n Cable
n Remote Control
n 12V DC 1 Amp
n Dimensions - 180(W) x 120(H) x 30(D)mm
REAR FRONT
MONITOR
ELR4+M
VB4112/3 .6
VB4112/3 .6
VB4112-SIDEVB4112-SIDE
VB4112-SIDE
INSIDE
OUTSIDE
Example
