Product guide

47
Sales: [phone] Technical: [phone] Accounts: [phone]
Mobile Solutions
DESCRIPTION
4 Channel Mobile DVR c/w 160Gb HDD
4 Channel Mobile DVR c/w 400Gb HDD
Mounting Kit for Lockable DVR Box
Lockable Anti Vibration Case for ELR4+M
(requires ELR4+M/MK)
Portable Viewer for ELR4+
USB Connector for Reading ELR4+ HDD's
on a PC
ORDER
CODE
ELR4
+M/160
ELR4
+M/400
ELR4+M/MK
ELR4
+MAVC
ELR4
+MPV
ELR+USB2
Visix
ELR4
+M
Mobile Digital Video Recorder
n 4 Channel Recor
der
n Recor
ding Speed upto 100 FPS, 25 FPS per each channel
n Removable HDD can be r
ead instantly on PC by provided software
n Easily replaceable HDD provides greater flexibility
n 4 alarm inputs / 1 relay output
n High resolution (360X288)
n Continuous recording, event recording modes, Various searching speed up to 8192 times
n Pre-alarmed recording of up to 900 frames
n System auto recovery after power failure guarantees robust security surveillance
n Remote surveillance and control via TCP/IP, LAN, web browser
n Recorded images can be seen and saved by provided software in AVI and BMP format
n 1 Audio Output
n Supports optional portable viewer for in vehicle viewing
n Optional anti-vibration mounting case
n 12V DC
The Visix ELR4+M is a 4 channel mobile digital recorder. Small and self-contained, this unit is
extremely easy to install and use - simply plug in and record. Ideal for vehicle security
applications, the ELR4+M offers a cost-effective, compact and reliable recording solution.
When it comes to reliability, the system auto recovery after power failure ensures continuous
security surveillance at all times. Additional features include a unique compression facility to
conserve disk space as well as compact flash backup with embedded viewing software.
Videcon
VB4112-SIDE / VB4112-SIDE-IR
Vandal Proof Side Camera
VB4112-SIDE VB4112-SIDE-IR
n CCD 1/3” 1/3”
n Resolution Colour 380 Lines 380 Lines
n Sensitivity Colour 0.5 Lux 0.5 Lux
n Sensitivity Mono N/A 0.0 Lux (IR LED On)
n Lens 3.6mm 3.6mm
n Infra Red LED N/A Built-in
n Voltage 12V DC 12V DC
n Dimensions (WxHxD) 80 x 99 x 70mm 80 x 99 x 70mm
Other Features
n Auto Gain Control
n Back Light Compensation
n IP67 Rated
n Ceiling or wall mounted
Videcon
VB4112/3.6 / VB4112/4.5
Vandal Proof Side Camera
n CCD 1/3”
n Resolution 380 Lines
n Sensitivity
0.1 Lux
n Lens Size 3.6mm or 2.45mm
n Voltage 12V DC
n Dimensions
55(Ø)mm
n Weight Approx. 600g
Other Featur
es
n Vandal Resistant
n Surface Mounting Adapter
n Auto White Balance
n Auto Gain Control
n Tri-Axis Gimbal
n Available in brushed steel or black casing
Order Codes
n VB4112/3.6 3.6mm Lens, Brushed Steel Case
n VB4112/2.45 2.45mm Lens, Brushed Steel Case
n VB4112/3.6-B 3.6mm Lens, Black Case
n VB4112/2.45-B 2.45mm Lens, Black Case
