Product guide

37
Sales: [phone] Technical: [phone] Accounts: [phone]
IP - V ideo Encoder and Decoder
Compact & Stable IP Video Decoder
n Embedded Linux Based
n Compact Size: 100 x 117.5 x 27 mm
High Frame Rate with Superior Video Quality
n Hardware MPEG4 & MJPEG decoding
n 25 fps at 720x576
n Bidirectional audio support
Powerful Features
n Connect up to 10 IP Video devices.
n Auto Scan function with definable
interval between 5 & 30 seconds
n Auto scene change and alarm
output activation trigger
ed by
remote motion detection or alarm
inputs on other IP devices
n Auto IP Sear
ch Function for local IP
Video devices
n OSD function
n Supports Pelco-D compatible
keyboards for remote telemetry
control
n 1 Alarm Input and 1 Output
n Easily accessed by using a web
browser
Wide Connectivity Support
n Static IP, Dynamic IP Support with
DDNS, PPPoE
Compact & Stable IP Video Server
n Embedded Linux Based
n Compact Size: 100 x 117.5 x 27 mm
High Frame Rate with Superior Video Quality
n MPEG4 and MJPEG selectable to
optimize Quality & Bandwidth
n 25 fps at 720x576 or 352 x 288
n Bidirectional Audio support
n Supports a maximum of 20
simultaneous users
Powerful Features
n Hardware based motion detection
using a 24 x 15 definable matrix
n Hardware based Moving Object
Tracking with auto zoom, adjustable
sensitivity and oscillating object
rejection
n 1 alarm input and 1 output
n 360 degree panoramic map
generation with intuitive PTZ control
n On screen virtual joystick
Software Support
n Pure web browser-based monitoring
with PTZ control, motion detection
and tracking and administration tools
n Simultaneous Monitoring & Recording
for up to 16 Ch with event recording
by Schedule, Alarm or Motion
Wide Connectivity Support
n Static IP, Dynamic IP Support with
DDNS, PPPoE
Videcon
VIP-R200
Network Video Server
Videcon
VIP-G200
Network Video Decoder
Compact & Stable IP Video Server
n Embedded Linux Based
n Compact Size: 100 x 175.5 x 27 mm
High Frame Rate with Superior Video Quality
n MPEG4 and MJPEG selectable to
optimize Quality & Bandwidth
n 25 fps at 720x576 or 352 x 288
n Bidir
ectional Audio support
n Supports a maximum of 20
simultaneous users
Powerful Features
n Hardware based motion detection
using a 24 x 15 definable matrix
n 2 alarm input and 2 output
Software Support
n Pure web browser-based Monitoring
n Simultaneous Monitoring & Recording
for up to 16 Ch with event recording
by Schedule, Alarm or Motion
Wide Connectivity Support
n Static IP, Dynamic IP Support with
DDNS, PPPoE
Videcon
VIP-O200
Network Video Server
The VIP-R200 is a compact single channel video server which accepts a standard coax camera input and converts it
t
o an MPEG4 or MJPEG video stream for Internet and LAN transmission.
It o
ffers features including motion detection, motion tracking (when used with a Concept Pro or other compatible
speed dome), alarm I/O, two way audio and precise PTZ control using the on-screen virtual joystick. It also supports
p
anoramic map generation to provide the operator with a global overview of speed dome coverage and quick access
to pre-programmed preset positions.
The VIP-O200 is a 4 channel version of the VIP-R200 offering all the same features but without motion tracking.
The VIP-G200 is a compact single channel video decoder which can connect to one or more IP video servers and
convert the MPEG4 or MJPEG stream back to a conventional coax output for use with a remote monitor or DVR.
It supports 2 way audio, alarm I/O, and also connection for a standard PTZ keyboard to allow remote control of a
speed dome over IP. The VIP-G200 can connect to a maximum of 10 other IP devices and provides a single sequence
output, definable by the user.
Both units are based on a stable embedded Linux platform, support resolutions of up to 720 x 576 @ 25FPS and are
easily accessed and administered using Internet Explorer or other compliant web browser.
Software development kits are available for those wishing to integrate the VIP range in to their own software
applications.
VIP-R200 / VIP-G200
VIP-O200
