IP - Speed Dome
Concept Pro
VHSD-870IPEXT
IP Speed Dome Camera
The IP Speed Dome Camera is designed particularly for outdoor surveillance with remote monitoring
and control applications. It provides high quality Motion JPEG and MPEG-4 video, with remote pan, tilt
and zoom control over IP networks.
The speed dome features an 18x optical zoom, autofocus lens and a 1/4 inch Sony ExView HAD
interlaced CCD image sensor. It has an IR-cut filter that can be automatically or manually removed,
depending on the light conditions. This enables the camera to capture color video in light conditions
down to 0.7 lux, and black and white video in dark conditions as low as 0.01 lux.
Due to our Micro-stepping technology, the speed dome can move to any positions at up to 360°/s as
well as ultra low speed down to0.05°/s. It covers continuous 360° panning and 90° tilting range and
features 128 preset positions and 8 Groups, 4 Pattern, 4 VST functions and 8 privacy zones.
The web viewer application included with the VHSD-870IPEXT allows complete camera control and
access to all the camera settings.
VHSD-SWAN/Y
VHSD-
SNA
VHSD-PENDANT VHSD-POLE CLAMP
T
he VHSD-8
7
0IPEX
T wall bracket fits
easily to the VHSD-/SNA to form a
pole s
w
an-neck br
ack
e
t
.
VHSD-CORNER MOUNT VHSD-/SNA
Compact & Stable IP V
ideo Server
n Embedded Linux Based
High Frame Rate with Superior V
ideo Quality
n MPEG4 and MJPEG selectable to optimize Quality &
Bandwidth
n 25 fps at 720x576 or 352 x 288
n Supports a maximum of 20 simultaneous users
Power
ful Features
n Har
dware based motion detection using a 24 x
15 definable matrix
n Hardware based Moving Object Tracking with
auto zoom, adjustable sensitivity and oscillating
object rejection
n 360 degree panoramic map generation with
intuitive PTZ control
n On screen virtual joystick
Software Support
n Pure web browser-based monitoring with PTZ
control, motion detection and tracking and
administration tools
Wide Connectivity Support
n Static IP, Dynamic IP Support with DDNS, PPPoE
VHSD-870EXT
n CCD
1/4” Sony Exview
n Resolution Colour
480 TVL
n Resolution Mono
520 TVL
n Sensitivity Colour
0.7 Lux
n Sensitivity Mono
0.01 Lux
n Lens Size
4.1 - 73.8mm
n Digital Zoom
12x
n Optical Zoom
18x
n V
oltage 24V AC
n Power Consumption 2.5A
n Dimensions (Without bracket) 214(Ø) x 230(H)mm
n IP Rating
IP66
n Weight 3.4Kg
Other Features
n True Day Night (ICR)
n Presets
n Pattern Tours
n Variable Speed Tracking
n Alarm Inputs
n Auto White Balance
n RS-485
n Auto Gain Control
n Back Light Compensation
n OSD
n Privacy Zones
n Flickerless
n Minimum Park Zone
n 1 Second Scheduling
n 3 YEAR WARRANTY
