IP - Speed Dome
Concept Pro
VHSD-810IPEXT
IP Mini Speed Dome Camera
The VHSD-810IPEXT is designed particularly for indoor and outdoor applications. Enclosed in a
discreet, vandal resistant weatherproof housing the VHSD-810IPEXT lends itself to the most hostile
and demanding en
vironments.
The speed dome features an 10x optical zoom, autofocus lens and a 1/4 inch Sony ExView HAD
interlaced CCD image sensor. It has an IR-cut filter that can be automatically or manually removed,
depending on the light conditions. This enables the camera to capture color video in light conditions
down to 0.7 lux, and black and white video in dark conditions as low as 0.02 lux.
Due to our Micro-stepping technology, the speed dome can move to any positions at up to 360°/s as
well as ultra low speed down to 0.05°/s. It covers continuous 360° panning and 90° tilting range and
features 128 preset positions and 8 Groups, 4 Pattern, 4 VST functions and 4 privacy zones.
The web viewer application included with the VHSD-810IPEXT allows complete camera control and
access to all the camera settings.
Compact & Stable IP V
ideo Server
n Embedded Linux Based
High Frame Rate with Superior V
ideo Quality
n MPEG4 and MJPEG selectable to optimize Quality &
Bandwidth
n 25 fps at 720x576 or 352 x 288
n Supports a maximum of 20 simultaneous users
Power
ful Featur
es
n Har
dwar
e based motion detection using a 24 x
15 definable matrix
n Hardware based Moving Object Tracking with
auto zoom, adjustable sensitivity and oscillating
object r
ejection
n 360 degree panoramic map generation with
intuitive PTZ control
n On screen virtual joystick
Software Support
n Pure web browser-based monitoring with PTZ
control, motion detection and tracking and
administration tools
Wide Connectivity Support
n Static IP, Dynamic IP Support with DDNS, PPPoE
n CCD 1/4” Sony Exview
n Resolution Colour 500 TVL
n Resolution Mono 570 TVL
n Sensitivity Colour 0.7 Lux
n Sensitivity Mono 0.02 Lux
n Lens Size 3.8 - 38mm
n Digital Zoom 10x
n Optical Zoom 10x
n Voltage 12V DC
n Power Consumption 0.8A
n Dimensions (Without bracket) 115(Ø) x 4.5(H)”
n IP Rating IP66
n Weight 3Kg
Other Features
n True Colour Mono (ICR)
n Presets
n Pattern Tours
n Variable Speed Tracking
n Alarm Inputs
n Auto White Balance
n RS-485
n Auto Gain Control
n Back Light Comepnsation
n OSD
n Privacy Zones
n SDNR
n Flickerless
n Minimum Park Zone
n 1 Second Scheduling
n 3 YEAR W
ARRANTY
n 12V DC PSU Required
Recommended Power supply - PCAM2, see page 27
n See page 30 for a selection of brackets
