IP - 1/3” IP Colour Mono Fixed Vandal Resistant Dome Camera c/w Lens
Concept Pr
o
VVP9324IPDN
IP Anti-Vandal Dome Camera
n Compact & Stable IP Dome Camera
Embedded Linux-based
Compact Size: 100 ø x 130 mm
WDR, Day and Night
n High Frame Rate with Superior Video Quality
MPEG4 and MJPEG selectable to optimize Quality & Bandwidth
High speed : 30 fps at 720 x 480, 25 fps at 720 x 576
Various Image Resolution 720 x 480, 320 x 258
Bidir
ectional Audio support
Max. 20 users Simultaneously
n Powerful Features
H/W based Moving Object Detection
Flexible Sector Masking using 24 x15 Matrix
V
arious Event Handling: Alar
m Out, Audio Out
1 CH. Loop-Through out for DVR, VCR & etc.
Built-in Sensor IO: 1 In/1 Out
n V
arious Software Support
Web Viewer
Pure web browser-based Monitoring
PTZ contr
ol, Motion detection setup and etc.
Remote Settings and Firmware Upgrading
Multi-view & Recor
d application (i-Pr
o)
Simultaneous Monitoring & Recor
ding up to 16 Ch.
Event Recording by Schedule, Alarm, Motion
Automatic HDD Shift in Recor
ding Mode.
SDK (Softwar
e Development Tool Kit) support
n Wide Connectivity Support
Static, Dynamic, PPPoE Support
Dynamic IP Support with DDNS
The VVP9324IPDN Fixed Dome Camera is a high-performance & intelligent camera for
professional indoor or outdoor surveillance and remote monitoring. It offers a
convenient, compact and cost-efficient solution with highly intelligent functions.
The VVP9324IPDN allows for easy and flexible installation on a wall or ceiling surface
and versatile 3 axis adjustment by panning, tilting and rotating the vari-focal lens to
any camera angle.
The VVP9324IPDN provides two-way audio support, including the option of using a
built-in microphone. This enables remote users not only to view, but also to listen in
on an area and communicate orders or requests to visitors or intruders. Thanks to its
high-quality image sensor with WDR and Day & Night as well as advanced image
processing, this camera delivers crisp and clear images also in poorly illuminated or
low-light conditions.
Supported by the superior video management software, the VVP9324IPDN provides
the perfect solution for securing shops and stores, schools, banks and other office
buildings over the local area network or across the Internet.
The VVP9324IPDN also supports hardware based motion detection based on a 24x15
grid. On motion detection, the camera can trigger an alarm output or audio alert.
These functions are built in to the camera hardware and are totally independent of a
PC system.
And, for advanced applications, an SDK is freely available to developers wishing to
customise the advanced functions of the VVP9324IPDN and incorporate them in to
their own applications.
n CCD 1/3”
n Resolution 550 Lines
n Sensitivity Colour 0.3 Lux
n Sensitivity Mono 0.1 Lux
n Lens Size 2-9-10mm Varifocal
n Voltage 12V DC / 24V AC
n Power Consumption 420mA
n Dimensions 100(Ø)x101(H)
n Weight Approx. 844g
Other Features
n True Colour Mono (ICR)
n Auto White Balance
n Auto Gain Control
n Back Light Compensation
n Flickerless
n IP65
n Service V
ideo Out
n Tri-Axis Gimbal
n 5 YEAR WARRANTY
