Product guide

Fax: [phone] Email: [e-mail] Web: www.videcon.co.uk
32
High Speed Domes - Concept Pro
Concept Pro
VA-KBDPRO+
Control Keyboard
RX100/VIDECONHSD
Up the Coax Receiver Box
VHSD-PSUEXT
3 AMP 24V AC Boxed PSU
n 3 axis PTZ contr
oller
n Compact & ergonomic design
n Multi protocol support including Pelco-D & Pelco-P
n Mixed protocol & baud rate support for each device
n Back lit display
n Controls VXM4 digital recorder range (see pages 39-42)
n Inter
face unit to allow control
of the dome using BBV up the
coax telemetry
n Requir
es BBV Keyboard
n External IP rated power
supply unit 24V AC
The VA-KBDPRO+ is a cost effective and compact tri-axis controller which can control
many different types of speed domes, mini pan/tilt cameras and pan/tilt heads. The
unit can also control one or more VXM4 digital recorders to form the central control
point of a multi camera/DVR system.
VXM4-RS232CONV
VXM4-RS232CONV
VA- MAT162
Videcon
VA-MAT162
Matrix
Videcon
VXM4-RS232CONV
RS485-RS232 Converter
n 16 inputs, 2 outputs
n Sequence mode
n PSU included
n Dimensions: 210mm(W) x 45mm(H) x 155mm(D)
n Compact RS485-RS232 converter
n Allows a VXM4 digital r
ecor
der to be dir
ectly
contr
olled from a VA-KBDPRO+
APPLICATION EXAMPLE
The VA-MAT162 is a compact matrix system which can switch
16 video inputs to 1 or 2 monitor outputs. It is controlled either
from the front panel or via RS-485 by a VA-KBDPRO+ PTZ
k
e
yboard. As well as individual channel to monitor selection,
the VA-MAT162 has a user defined sequence mode with
adjustable dwell time and options to exclude particular
channels fr
om the s
equenc
e
.
Interested in a Demonstration?
Call [phone] for details
