Product guide

31
Sales: [phone] Technical: [phone] Accounts: [phone]
High Speed Domes - Concept Pro
Concept Pr
o
VHSD-8
70EXT / VHSD-970EXT
Day/Night External High Speed Dome
VHSD-SWAN/Y
VHSD-870EXT VHSD-970EXT
n CCD 1/4” Sony Exview 1/4” Sony Exview HAD
n Resolution Colour 480 TVL 530 TVL
n Resolution Mono
520 TVL
530 TVL
n Sensitivity Colour 0.7 Lux 1.4 Lux
n Sensitivity Mono 0.01 Lux 0.01 Lux
n Lens Size
4.1 - 73.8mm 3.4 - 122.4mm
n Digital Zoom 12x 12x
n Optical Zoom 18x 36x
n V
oltage 24V AC 24V AC
n Power Consumption
2.5A 2.5A
n Dimensions (Without bracket) 214(Ø) x 230(H)mm 214(Ø) x 230(H)mm
n IP Rating
IP66 IP66
n Weight 3.4Kg 3.4Kg
Other Features
n True Day Night (ICR)
n Presets
n Pattern Tours
n Variable Speed Tracking
n Alarm Inputs
n Auto White Balance
n RS-485
n Auto Gain Control
"What we have here is a fast, versatile and highly adaptable dome
camera, suited to a very wide range of applications"
(Security Installer - March 2007)
VHSD Brackets & Accessories
Suitable for a wide variety of outdoor surveillance applications, the VHSD-870EXT features 127
preset positions, 4 pattern tours, 8 privacy zones and 8 variable speed tracking functions. This wide
array of features can be combined in to a single group function allowing virtually 'hands-free'
operation once the group is activated.
8 alarm inputs and 4 alarm outputs at the head offer plenty of flexibility for connection of proximity
sensors and other external equipment. Including support for Pelco P and Pelco D protocol, the VHSD-
870EXT is fully compatible with the vast majority of control equipment available today.
Connect to the VHSD external high speed demo site at www.videcon.co.uk
VHSD-SNA
VHSD-PENDANT VHSD-POLE CLAMP
The VHSD-870EXT & VHSD-970EXT
w
all br
ack
et fits easily to the VHSD-
/SNA to form a pole swan-neck
br
ack
e
t
.
n Back Light Compensation
n Wide Dynamic Range (VHSD-970EXT Only)
n OSD
n Privacy Zones
n SDNR (VHSD-970EXT Only)
n Flickerless
n 3 YEAR WARRANTY
VHSD-CORNER MOUNT VHSD-/SNA
Interested in a Demonstration?
All members of our field sales team have a
fully operational VHSD-870EXT unit to hand,
so they can are able to give you a
comprehensive product demonstration on site
or at your premises. Please call our sales
team on [phone] to arrange an
appointment.
