V ehicle Solutions - 1/3" Colour and Colour Mono Fixed Vandal Resistant Vehicle Moumt Camera c/w Lens
Videcon
VB4112-SIDE / VB4112-SIDE-IR
Vandal Proof Camera
VB4112-SIDE VB4112-SIDE-IR
n CCD 1/3” 1/3”
n Resolution Colour 380 Lines 380 Lines
n Sensitivity Colour 0.5 Lux 0.5 Lux
n Sensitivity Mono N/A 0.0 Lux (IR LED On)
n Lens 3.6mm 3.6mm
n Infra Red LED N/A Built-in
n Voltage 12V DC 12V DC
n Dimensions (WxHxD) 80 x 99 x 70mm 80 x 99 x 70mm
Other Features
n Auto Gain Control
n Back Light Compensation
n IP67 Rated
n Ceiling or wall mount
Videcon
VB4112/3.6 / VB4112/2.45
Vandal Proof Camera
n CCD 1/3”
n Resolution 380 Lines
n Sensitivity 0.1 Lux
n Lens Size 3.6mm or 2.45mm
n Voltage 12V DC
n Dimensions 55(Ø)mm
n Weight Approx. 600g
Other Features
n Vandal Resistant
n Surface Mounting Adapter
n Auto White Balance
n Auto Gain Control
n Tri-Axis Gimbal
n Available in brushed steel or black casing
Order Codes
n VB4112/3.6 3.6mm Lens, Brushed Steel Case
n VB4112/2.45 2.45mm Lens, Brushed Steel Case
n VB4112/3.6-B 3.6mm Lens, Black Case
n VB4112/2.45-B 2.45mm Lens, Black Case
Enclosed in a hardened polycarbonate dome and IP65 weather-resistant casing, the
VB4112 provides an effective, robust surveillance solution for a range of vehicle security
applic
ations.
The VB4112 features a 3.6mm or 2.45mm fixed lens as standard and is available in either
a black or brushed steel finish. The unit comes complete with both standard and angled
surface mount adaptors and can be easily installed on the ceiling or wall, surface or flush
mounted.
The VB4112-side is a high performance, vandal resistant side view camera. Designed specifically
for the mobile security market, the camera can be installed easily on the wall or ceiling and can be
mounted to face multiple directions on the vehicle.
Featuring a robust, IP67 waterproof casing the camera is particularly effective in harsh,
demanding environments.
VB4112-SIDE-IR
VB4112-SIDE
The VB4112-SIDE and VB4112-SIDE-IR can be
side-mounted and positioned to be able to
view the entire length of a vehicle.
Example
See pages 47 - 48 for more vehicle security products
