Vandal Resistant Domes - 1/3" Colour Mono Vandal Resistant IR Dome Camera c/w Lens
Videcon
DSIRHR
Vandal Resistant IR Dome Camera
Videcon
DSIRHRV / DSIRHRV/S
Vandal Resistant IR Dome Camera
n CCD 1/3”
n Resolution 480 Lines
n Sensitivity Colour 0.1 Lux
n Sensitivity Mono 0 Lux
n Number of Infra Red LEDs 24
n IR Range 20m
n Lens Size 3.6mm
n Voltage 12V DC
n Power Consumption 1A
n Dimensions 93(Ø) x 80(H)mm
n Weight Approx. 540g
Other Features
n True Colour Mono (ICR)
n Auto White Balance
n Auto Gain Control
n Back Light Compensation
n Tri-Axis Gimbal
n CCD 1/3”
n Resolution Colour 540 Lines
n Resolution Mono
625 Lines
n Sensitivity Colour 0.1 Lux
n Sensitivity Mono 0 Lux
n Number of Infra Red LEDs
24
n IR Range 30m
n Lens Size 4-9mm Varifocal
n V
oltage
12V DC
n Power Consumption 1A
n Dimensions 120(Ø) x 96(H)mm
n W
eight
Appr
ox. 600g
Other Featur
es
n Auto White Balance
n Auto Gain Control
n Back Light Compensation
n T
ri-Axis Gimbal
DSIRHRV/S
DSIRHRV
Designed for areas that are prone to attack, the DSIRHR is enclosed in a vandal resistant
and weatherproof housing. The robust design of the DSIRHR makes it a highly visible
camera that serves as an effective deterrent in hostile environments.
Designed for areas that are prone to attack, the DSIRHRV is enclosed in a vandal resistant and
weatherproof housing. The robust design of the DSIRHRV makes it a highly visible camera that
can act as a deterrent in hostile environments.
This high-resolution ball dome comes complete with 24 in-built IR LEDs and CDS sensor.
Amongst a wide array of functions, the DSIRHRV features an external zoom/focal adjustment
for ease of setup.
Locking Grub Screw
CDS Sensor
Infrared LED
Operation of degree
(Tilt : 10~ 90º/ Manual)
Fixed Board Lens
Operation of degree
(Pan : 0~355º/Manual)
96
120
External Zoom / Focal Adjustment
Panning upto 360º
Tilting 10º ~ 90º
