Product guide

KT&C
KPC-S38 Range
Monochrome Board Camera
KT&C
KPC-S20C Range
Colour Boar
d Camera
KT&C
KPC-S700 Range
Colour Board Camera
Fax: [phone] Email: [e-mail] Web: www.videcon.co.uk
14
n CCD
1/4” Sony Super HAD
n Resolution
380 Lines
n Sensitivity
1.0 Lux
n Lens Options
3.6mm / 3.7mm Coned/ Flat
Pinhole /4.3mm Coned Pinhole
n V
oltage
12V DC
n 22mm Square Cased Board
n CCD 1/3” Sony Super HAD
n Resolution 380 Lines
n Sensitivity 0.5 Lux
n Lens Options 3.6mm / 3.7mm Coned/ Flat
Pinhole /4.3mm Super Coned Pinhole /
4-8mm V/focal
n V
oltage
12V DC
n 30mm Square Cased Board
DESCRIPTION
1/4” 380 line, 0.5 lux, 3.6mm lens, 22mm sq cased board 9-15V DC
1/4” 380 line, 0.5 lux, 3.7mm cone pinhole lens, 22mm sq cased
board 9-15V DC
1/
4” 380 line, 0.5 lux, 3.7mm flat pinhole lens, 22mm sq cased
board 9-15V DC
1/4” 380 line, 0.5 lux, 4.3mm super cone pinhole lens, 22mm sq
cased board 9-15V DC
1/3” 380 line, 0.5 lux, 3.6mm lens, 30mm sq cased board, 9-15V DC
1/3” 380 line, 0.5 lux, 3.7mm cone pinhole lens, 30mm sq cased
board, 9-15V DC
1/3” 380 line, 0.5 lux, 3.7mm flat pinhole lens, 30mm sq cased
board, 9-15V DC
1/3” 380 line, 0.5 lux, 4.3mm super cone pinhole lens, 30mm sq
cased board, 9-15V DC
1/
3” 380 line, 0.5 lux, 4-8mm v/focal lens, 30mm sq cased board,
9-15V DC
1/3” 480 line, 1.0 lux, 3.6mm lens, 38mm sq cased board, 9-15V DC
1/3” 480 line, 1.0 lux, C/CS lens mount, 38mm sq cased board, 9-
15V DC
1/3” 480 line, 1.0 lux, 3.7mm cone pinhole lens, 38mm sq cased
board, 9-15V DC
1/3” 480 line, 1.0 lux, 3.7mm flat pinhole lens, 38mm sq cased
board, 9-15V DC
1/3” 480 line, 1.0 lux, 4-8mm v/focal lens, 38mm sq cased board,
9-15V DC
1/3” 480 line, 1.0 lux, 4-8mm AI v/focal lens, 38mm sq cased
board, 9-15V DC
ORDER CODE
VB456P
KPC-S20CB
KPC-S20CP1
KPC-S20CP3
KPC-S20CP4
KPC-S700CB
KPC-S700CP1
KPC-S700CP3
KPC-S700CP4
KPC-S700CV
KPC-S38CZHB
KPC-S38CZHCM
KPC-S38CZHP1
KPC-S38CZHP3
KPC-S38CZHV
KPC-S38CZHVA1
Colour Board Cameras
n CCD 1/3” Sony Super HAD
n Resolution 480 Lines
n Sensitivity 1.0 Lux
n Lens Options 3.6mm / 3.7mm Coned/ Flat
Pinhole / 4.8mm V/focal /
AI V/focal
n Voltage 9-15V DC
Other Features
n C/CS lens mount option
n 38mm Square Cased Board
n Audio optional
n 3 x digital zoom
Technical Tips
C
O
VERT CAMERAS
Covert cameras tend to be built into an array of common
pr
oduct
s such as PIR
s
, junction bo
x
es and smoke detectors.
Small bo
ar
d c
ameras are also available that can be fitted into
suit
able items already on site.
They have very small front 'objective' lenses, which mean that
they can be put behind very small holes, and are virtually
unde
t
ectable. Straight and right-angled models are available to
facilitate the mounting of the camera and to reduce the depth
required behind the concealing surface. Due to the small
objectiv
e lens
, pin-hole lens
e
s c
annot gather as much light as
c
on
ventional lenses and so their use dictates that the scene
illumination is better than would otherwise be required.
Typically the maximum apertures available on pin hole lenses is
F2.5 to F3.5 which is approximately 2 to 3 stops less than
s
tandard lenses. Hence between 4 and 8 times the normally
quoted minimum scene illumination is required for the camera to
produce a usable picture.
If you don’t see what you are looking for please
ask, w
e c
an source it for you
