VLP5026
Housed IR Camera
9
Sales: [phone] Technical: [phone] Accounts: [phone]
Cameras - 1/3" Colour Mono Camera Housed c/w IR LED
n CCD
1/3”
n Resolution Colour
550 Lines
n Sensitivity Colour
0.3 Lux
n Sensitivity Mono
0.0 Lux IR LED ON
n Sensitivity DSS Colour
0.008 Lux
n Sensitivity DSS Mono
0.001 Lux
n Infra Red IR LEDs
9 (Hybrid)
n IR Range
60m
n Lens Size
7.5-50mm Varifocal
n V
oltage 12V DC
n Power Comsumption
1.5A / 18W (Max)
n Dimensions (WxHxD)
111 x 213 x 289.59mm
n W
eight Approx. 1.65Kg
Other Featur
es
n T
rue Colour Mono (ICR)
n Auto White Balance
n Auto Gain Control
n Back Light Compensation
n 2x Digital Zoom
n SDNR
n Flickerless
n Service Video Output
n Built in Heater & Blower
n Cable Management Bracket
n Internal / External
n Weatherproof
n 5 YEAR WARRANTY
BUILT-IN HEATER &
BLOWER
The VLP5026 is one of the largest cameras in the VLP range and has a strong visual
presence. The unit is housed in a unique weatherproof housing and comes complete with
a convenient fixing plate and cable managed bracket to guarantee a quick and easy
install.
The camera boasts an impressive 550TVL and features a 7.5-50mm varifocal lens.
Incorporating 9 (Hybrid) IR LEDs the VLP5026 is able to capture images at a range of
60m in light levels as low as 0.0 Lux (IR LED on).
VLP5026
Camera
9m
VLP4026 / VLP4526
Camera
50m
Technical Tips
Home Office recommendations, incorporated into European Standards for CCTV Systems specify that in order to be able to recognise
a person he or she should occupy at least 50% of monitor height. Also if it is necessary to be able to positively identify an unknown
per
s
on then his or her image should occupy 120% or more of the screen's height.
W
hen de
signing a s
y
s
t
em it is as
sumed that the per
son to be recognised or identified is the European Standard height of 1.6m tall and
is standing upright!
Hence for recognition, if a 1.6m person must occupy 50% of screen height, then the monitor must cover no more than 2 x 1.6m = 3.2m
at the distance from the camera where the person is standing.
W
ith the VLP40
2
6, VLP4
526 and the VLP5026 the standard of recognition can be achieved at the following distances:
