Product guide
Concept Pro
VLP15 Range
Housed IR Camera
Concept Pro
VLP3026G
Housed IR Camera
T
emperature Balance Valve
Prevents the risk of condensation inside
the camera
12 IR LED’S
18 IR LED’S
Temperature Balance Valve
All external camera housings are susceptible to condensation caused by temperature imbalance.
The VLP range incorporates a specially designed Temperature Balance Valve which eliminates
the conditions that cause condensation build up
.
n CCD
1/3”
n Resolution Colour
550 Lines
n Sensitivity Colour 0.3 Lux
n Sensitivity Mono
0.0 Lux IR LED ON
n Infra Red IR LEDs
18
n IR Range 30m Range
n Lens Size
3.8-9.5mm V
arifocal
n V
oltage
12V DC
n Power Comsumption 500mA / 6W (Max)
n Dimensions
65 dia. x 179.5mm (H)
n W
eight
Approx. 350g
Other Featur
es
n True Colour Mono (ICR)
n Auto White Balance
n Auto Gain Contr
ol
n IP65
n Internal / External
n Weatherproof
n 5 YEAR WARRANTY
The VLP collection offers a versatile range of weatherproof colour mono cameras that are suitable for both internal and external
applications.
The VLP collection provides a flexible, reliable solution 24hrs a day. Featuring 12 in-built IR LEDs, both the VLP15 and VLP30 are able to
operate in light levels as low as 0.3lux (day) and 0.00lux (IR LED on).
7
Sales: +44 (0)1924 528000 Technical: +44 (0)1924 528004 Accounts: +44 (0)1924 528006
Cameras - 1/3" Colour Mono Camera Housed c/w IR LED
VLP1514/4
VLP1514/6 VLP1524/4 VLP1524/6
n CCD
1/3” 1/3” 1/3” 1/3”
n Resolution Colour
380 Lines 380 Lines 480 Lines 480 Lines
n Sensitivity Colour
0.1 Lux 0.1 Lux 0.3 Lux 0.3 Lux
n Sensitivity Mono
0.0 Lux IR LED ON 0.0 Lux IR LED ON 0.0 Lux IR LED ON 0.0 Lux IR LED ON
n Infra Red IR LEDs
12 12 12 12
n IR Range
15m 15m 15m 15m
n Lens Size
4.3mm 6mm lens 4.3mm 6mm lens
n V
oltage 12V DC 12V DC 12V DC 12V DC
n Power Comsumption
300mA / 4.2W (Max) 300mA / 4.2W (Max) 300mA / 4.2W (Max) 300mA / 4.2W (Max)
n Dimensions
50(Ø) x 135mm (H) 50(Ø) x 135mm (H) 50(Ø) x 135mm (H) 50(Ø) x 135mm (H)
n W
eight Approx. 293g Approx. 293g Approx. 293g Approx. 293g
Other Featur
es
n Auto White Balance
n Auto Gain Control
n IP65
n Internal / External
n Weatherproof
n 5 YEAR WARRANTY
