Cat-6 Plenum
23 AWG 4 Pair Communications Cable
Communications Cable
FREQUENCY
(MHz)
CHAR. IMPEDANCE
(Ohms)
(+/-15)
RETURN LOSS
(min)
ATTENUATION
(max)
PSNEXT
(dB/100m)
(min)
NEXT
(dB/100m)
(min)
ACRF
(dB/100m)
(min)
PSARCRF
(dB/100m)
(min)
1 100 20.0 2.0 72.3 74.3 67.8 64.8
4 100 23.0 3.8 63.3 65.3 55.7 52.7
8 100 24.5 5.3 58.8 60.8 49.7 46.7
10 100 25.0 6.0 57.3 59.3 47.8 44.8
16 100 25.0 7.6 54.8 56.3 43.7 40.7
20 100 25.0 8.5 52.8 54.8 41.7 38.7
25 100 24.3 9.5 51.3 53.3 39.8 36.8
31.25 100 23.6 10.7 49.9 51.9 37.9 34.9
62.5 100 21.5 15.4 45.4 47.4 31.8 28.8
100 100 20.1 19.8 42.3 44.3 27.8 24.8
125 100 19.4 22.4 40.9 42.9 25.8 22.8
155.52 100 18.8 25.2 39.4 41.4 23.9 20.9
175 100 18.4 26.9 38.7 40.7 22.9 19.9
200 100 18.0 29.0 37.8 39.8 21.7 18.7
250 100 17.3 32.8 36.3 38.3 19.8 16.8
ACR (min) @ 100 MHz = 24.1 dB/100m Mutual Cap. = 14pF/ft. Mutual Cap. = 7.1 /100
ACR (min) @ 200 MHz = 10.0 dB/100m Operating Temperature: -10 ˚C to 75 ˚C
Nominal Velocity of Probagation (NVP) = 72% Propagation Delay Skew: 45 ns/100 m (max)
Electrical Performance
Ʊ
CERRO
FINISHED
GOODS PART # DESCRIPTION PUT-UP
PACKAGE
TYPE
SPOOLS/COILS
PER
MASTER
CARTON
SHIPPING
WEIGHT PER
MASTER
CARTON
UPC CODE
2703-0144K5
23G 4P CAT6 CMP PLEN WHI 1000FT
1000 Box N/A 22.3 048243767052
2703-0124K5 23G 4P CAT6 CMP PLEN BLU 1000FT 1000 Box N/A 22.3 048243767007
