TIC126 SERIES
SILICON CONTROLLED RECTIFIERS
3
 
APRIL 1971 - REVISED SEPTEMBER 2002
Specifications are subject to change without notice.
THERMAL INFORMATION
Figure 1. Figure 2.
Figure 3. Figure 4.
AVERAGE ON-STATE CURRENT
T
C
- Case Temperature - °C
30 40 50 60 70 80 90 100 110
I
T(AV)
- Maximum Average On-State Current - A
0
2
4
6
8
10
12
14
16
TI03AE
DERATING CURVE
Φ = 180º
Continuous DC
Conduction
Angle
Φ
0° 180°
MAX
ANODE
POWER
LOSS
I
T
- Continuous On-State Current - A
0·1 1 10 100
P
A
- Max Continuous Anode Power Dissipated - W
0·1
1
10
100
TI03AF
T
J
= 110°C
ON-STATE CURRENT
vs
SURGE ON-STATE CURRENT
Consecutive 50 Hz Half-Sine-Wave Cycles
110100
I
TM
- Peak Half-Sine-Wave Current - A
1
10
100
TI03AG
CYCLES OF CURRENT DURATION
vs
T
C
≤
70°C
No Prior Device Conduction
Gate Control Guaranteed
TRANSIENT THERMAL RESISTANCE
Consecutive 50 Hz Half-Sine-Wave Cycles
110100
R
θ
JC(t)
- Transient Thermal Resistance - °C/W
0.1
1
10
TI03AH
CYCLES OF CURRENT DURATION
vs
