CATC MERLIN’S WAND 1.22 CHAPTER 2
User’s Manual Getting Started
• Merlin’s Wand Info - Displays details about Merlin’s Wand.
• At the bottom of the interface is the Logs window, which
contains tabs for the Event Log and the Script Log:
• Event Log - Maintains a log of the commands issued by
Merlin’s Wand and the events that ensue, such as a reply
by another device.
• Script Log - Maintains a record of the commands issued
by Script Manager and the events resulting from these
commands. If line numbers are referenced in the Script
Log, double-clicking on the line number will move the
cursor to that line in the Script Manager window.
2.6 Menus
The menu bar at the top of the application window contains the following
menus of pull-down commands:
Table 1: Menu Bar Commands
File Menu
Command Function
New Script Creates a new script file
Open Script... Opens a script file
Close Script Closes a script file
Save Script Saves a script file
