5. Press Enter.
6.2.8 Add a measurement
You can add measurements to a job before or after you collect the data. After you collect
data, press F9 Store Data and add a measurement.
Note
A job can contain different measurement types.
Procedure
1.
Open a saved job.
2. Press F4 Add New Meas.
Each time you press F4 Add New Meas, a new measurement is added. "No Data"
appears in the bottom of the screen for each measurement.
6.2.9 Delete a measurement
1. Open a saved job.
2. Press F3 Edit This Job.
3. Use the up and down arrow keys to select a measurement.
4. Press F6 Delete Meas.
5. Press Enter.
6.2.10 Delete data from the current measurement point
1. Open a saved job.
2. Use the up and down arrow keys to select a measurement in the job.
3. Press F5 Clear Data.
The measurement displays "No Data" on the Current Job screen.
4. Press Enter.
6.2.11 Save a job to equipment in a route
You can save a job to equipment in a route. When you transfer the job to AMS Machinery
Manager, the data is assigned to that equipment in the database. Use this when you
collect data outside the route. When you select the equipment, the analyzer uses the
equipment ID and description in the corresponding fields in Job Setup.
Procedure
1.
Open a saved job.
Analyze and Advanced Analyze
93
