2. Press F1 Change Job > F3 Change Location to view jobs in internal memory or a memory
card.
3.
Use the up and down arrow keys to view the jobs.
To sort the jobs, press ALT > F1 Sort by Alphabet or ALT > F3 Reverse Sort Order.
4. Press F4 Select Job.
The Current Job screen displays the job.
6.2.5 Change the job ID
1. Open a saved job.
2. Press F3 Edit This Job > F2 Edit Job ID.
3. Enter up to 10 characters. You cannot use the following characters: \ . : / * # ? " | < >
4. Press Enter.
6.2.6 Edit the equipment ID and description in a job
1. Open a saved job.
2. Press F3 Edit This Job.
3. Set the following options, as necessary.
Option Description
F7 Edit Equip ID Enter up to 10 characters to identify the equipment.
F8 Edit Equip Desc Enter up to 28 characters to describe the equipment.
4. Press Enter.
6.2.7 Edit the measurement ID and description in a job
1. Open a saved job.
2.
Press F3 Edit This Job.
3. Select a measurement in the job.
4. Press F5 Edit Meas, and set the following options as necessary.
Option Description
F2 Edit ID Enter up to three characters to identify the measurement point for input 1.
F3 Edit ID Enter up to three characters to identify the measurement point for input 2.
F4 Edit ID Enter up to three characters to identify the measurement point for input 3.
F5 Edit ID Enter up to three characters to identify the measurement point for input 4.
F6 Edit Descript Enter up to 20 characters to describe the equipment.
Analyze and Advanced Analyze
92
