4.6.6 Delete route data from the current measurement point
Delete data if you collected data for the wrong measurement point or have bad data.
Procedure
1.
Activate a route.
2. Ensure the desired measurement point is displayed.
3. From the Route Data Collection screen, press ALT > F8 Clear Data.
4. If multiple data sets are stored on the route point, select a set of data to delete and
press F9 Delete Data Set.
5. Press Enter.
The Status field displays "Not Measured".
4.6.7 Status messages
Status messages may appear in the Status field on the Route Data Collection screen for a
measurement point. The values that cause these status messages are set in the Analysis
Parameter set in AMS Machinery Manager.
Option Description
Bad Reading The value is lower or higher than the valid signal range of the measurement
point. Check these settings from the Point Setup screen in the AMS
Machinery Manager Database Setup application.
Bad Sensor The voltage level is below or above a certain level, the sensor or cable is not
connected, or the sensor is electrically open or shorted. Press Enter to
collect data anyway, or press Back to stop the measurement. The data is
marked as collected with a bad sensor.
Note
You must set up AMS Machinery Manager Data Transfer to accept bad
sensor data before you can download this data to the AMS Machinery
Manager database.
Field Alert You added a field alert.
High Alarm 1 The overall Alert value exceeded Dual Upper Absolute and Out of Window
Absolute alarms.
High Alarm 2 The overall Fault value exceeded Dual Upper Absolute and Out of Window
Absolute alarms.
High Signal The signal is less than the upper validity limit of the sensor signal and
greater than the weak side value. In Dual Lower Delta alarms, the high
signal can occur when the baseline value plus the weak side value is
exceeded, but the value is less than the upper sensor validity range.
Route
72
